C
Messages
Topics Covered in this Appendix
▪ The Status Messages
The Status Messages
Displayed in the status bar, status messages are either general or specific to the chosen drying mode and
constantly notify you of the dryer’s current state.
Table C-1 Status messages for both the continuous flow and staged batch modes
Message Drying modes Occurrence Description
Dryer Started Continuous flow,
staged batch Displayed once Start is pressed
on the control panel The dryer is in operation
Dryer Stopped Continuous flow,
staged batch Displayed once Stop is pressed
on the control panel, or Stop
Dryer is clicked on your dryer’s
remote web application The dryer is not in operation
Loading Continuous flow,
staged batch Displayed when the load auger
is turning Indicates the time remaining on
the out of grain timer
Drying Continuous flow,
staged batch In staged batch, displayed
during the drying phase in either
the time or time and temperature
control scheme, once the drying
time starts In staged batch, indicates the
time remaining on the drying timer
of the selected control scheme
(time or time and temperature)
Hi-Heat Drying
(time) Staged batch Displayed during the drying
phase in the dual-setpoint time
control scheme, once drying
time 1 starts Indicates the time remaining on
the drying 1 timer
Hi-Heat Drying
(temp) Staged batch Displayed during the drying
phase in the dual-setpoint tem-
perature control scheme, before
the grain setpoint 1 is reached Indicates the difference (in
degrees) between grain setpoint 1
and the grain’s actual
temperature
Low-Heat Drying
(time) Staged batch Displayed during the drying
phase in the dual-setpoint time
control scheme, once drying
time 2 starts Indicates the time remaining on
the drying 2 timer
Low-Heat Drying
(temp) Staged batch Displayed during the drying
phase in the dual-setpoint tem-
perature control scheme, before
the grain setpoint 2 is reached Indicates the difference (in
degrees) between grain setpoint 2
and the grain’s actual
temperature
Cooling Staged batch Displayed during the cooling
phase Indicates the time remaining on
the cooling timer
PNEG-1851 Vision N2 97
