Product description
1.3 Technical data
Technical data
Power supply
Supply voltage U
nom
= 24 V AC (20 … 53 V), 50/60 Hz or
= 24 V DC (20 … 72 V)
Power consumption approx. 6 VA
Fuse 1 A, slow-blow
Electrical connection
Component multiple plug acc. to DIN 41 612, series F
48-pole (d, b, z) with coding holes
Module in carrier
BGT 596 or BGT LOG 571
suitable multipoint connector acc. to DIN 41 612
with connection via standard technologies
Housing type 505 via screw terminals max. 1 x 1.5 mm 2
Indicating elements
LED on front panel green BA: communication signal PROFIBUS
red (flashing): DISBUS/LOGBUS failure
red (permanent): failure
green on: operating voltage on
Measurement data input DISBUS
Data transmission DISBUS (digital data transmission)
Connection cable 2-wire, unscreened (standard cable)
Cable length max. 1000 m
Measurement data input LOGBUS
Data transmission LOGBUS (digital data transmission)
Connection cable connection via BUS plug
PC interface
Interface standard RS 232 C
Cable length max. 15 m
Transmission rate 1) 300, 600, 1200, 2400, 4800, 9600 and
19200 baud
Transmission format 8 data bits, 1 stop bit, even parity
Plug on the front panel D-SUB plug connector, 9-pole, pins
1) adjustable via DIL switch on the component
