24 VEGACOM 557 Profibus FMS
Setup
Number of external active stations:
- Number of active stations not acquired in the topology file. This adjustment is necessary for
the calculation of the bus parameter block.
Max. participant address (HSA):
- This is the highest bus address of an active bus participant.
Baud rate:
- The baud rate of the transmission speed.
Default SAP:
- On receipt of a telegram without Destinations-SAP number, the CP dials the Default SAP.
No. of telegram repeats:
- This value states how often a telegram should be repeated if the acknowledgement is not
correct.
Medium redundancy:
- No redundancy
Bus parameters:
- The bus parameters can be reset to default with the F1 key depending on the adjusted
baud rate.
SINEC-NCM (END)
Edit network parameter - Global Source: DEMO1NCM.BPB
————————————————————————————————————————
Highest active L2-address within network data file : 13
additive topology figures :
No. of external act. stations : 2 max. particip. addess (HSA) : 31
————————————————————————————————————————
Busparameter figures :
Baud rate : 500000 Baud
Default SAP : 61
Number of telegram-repeats (Max. Retry Limit) : 1
Medium redundancy : no redundancy
Busparameter data:
Slot-Time (TSL) : 1000 Bit times 2.0000 msec
Setup-Time (TSET) : 80 Bit times .16000 msec
min. Station-Delay (min TSDR) : 80 Bit times .16000 msec
max. Station-Delay (max TSDR) : 360 Bit times .72000 msec
Target-Rotation-Time (TTR) : 15000 Bit times 30.000 msec
GAP-actualisation factor (G) : 30
F F F F F F F F HELP
1 CALCULATE 2 3 4 5 6 7 TAKE OVER 8 CHOICE
