Setup
Unconfirmed orders:
- This field remains empty as this is reserved for the service "Indicate variable" and this is no
Gateway function.
Local LSAP:
- The Service Access Point (SAP) for the CP5431. With MSAZ (Master-Slave acyclical) con-
nections this value is set automatically to the Poll-SAP 58.
Strange LSAP:
- This is the SAP from VEGACOM 557 Gateway. The values 0 … 5 are permitted.
Strange L2 address:
- The instrument address of VEGACOM 557 Gateway. This address has to correspond with
the address setting on the Gateway.
max. PDU length:
- The max. telegram length must be set to 241.
Password:
- No entry or 0, no password
Access to variables:
- No entries. No type test possible, as the read in measured values are structures.
CP Connection planning Source C:QMESSW
———————————————————————————————————————
Communication referenc: 2 Kind of connection : MSAZ
Order planning Monitoring intervall : 0 * 10 ms
SSNR: 0
ANR : 1
ANZW: MW 100
unconfirmed orders:
local connection planning
local LSAP : 58 max. PDU-length : 241
distant connection planning
Strange LSAP : 0 strange L2-address : 12
Password :
Access to variables ( GET OV )
F F F F F F F F HELP
1 +1 2 -1 3 INPUT 4 REP VAR 5 DELREPVAR 6 DELETE 7 TAKE OVER 8 CHOICE
