Installation Guide
Power Monitoring
E50F2A, E50F5A
TM
CP Name Type NV Num. R/W Applies To Range Default Value Description
INFORMATION
cpMeterModel
SCPTpartNumber - R “Meter” Function
Block
- - Meter Manufacturer and Model, stored as an
ASCII string (e.g. “Veris Industries E50F2A”).
cpSerialNumber SCPTserialNumber - R “Meter” Function
Block
- - Meter Serial Number.
cpDevMajVer SCPTdevMajVer - R “NodeObject”
Function Block
- - Firmware Major Version (Gateway). See
nvoFullFwRevision for RS, OS firmware
revisions.
cpDevMinVer SCPTdevMinVer - R “NodeObject”
Function Block
- - Firmware Minor Version (Gateway). See
nvoFullFwRevision for RS, OS firmware
revisions.
INSTALLATION DETAILS
cpSystemType
UCPTsystemType
(UCP_Type_3 w/o
resource files)
(SNVT_count ref.)
12 R/W “Meter” Function
Block
10, 11, 12,
31, 40
40 System Type (see installation instructions for
more detail).
10 Single Phase: A + N
11 Single Phase: A + B
12 Single Split Phase: A + B + N
31 3 Phase Delta, A + B + C, no N
40 3 Phase Wye, A + B + C + N
Note: Only the indicated phases are monitored
for phase loss.
cpDisplayUnits UCPTdisplayUnits
(UCP_Type_4 w/o
resource files)
(SNVT_count ref.)
13 R/W “Meter” Function
Block
0, 1 1 (IEEE) Screen Display Units
0 = IEC (U, V, P, Q, S)
1 = IEEE (VLL, VLN, W, VAR, VA)
cpCtPriRatio UCPTctPriRatio
(UCP_Type_5 w/o
resource files)
(SNVT_count ref.)
14 R/W “Meter” Function
Block
20 - 5000(A) 100(A) CT Ratio – Primary (from CT rating)
cpPtRatio UCPTptRatio (UCP_
Type_7 w/o resource
files)
(SNVT_count ref.)
16 R/W “Meter” Function
Block
1 – 32000
(scaled 0.01-
320.00)
100 (scaled 1:1) PT Ratio. This value is scaled by 100 (200 = PT
ratio of 2:1). Set to 100 (1.00:1) for no PT.
cpSystemVoltage UCPTsysVoltage
(UCP_Type_8 w/o
resource files)
(SNVT_count ref.)
17 R/W “Meter” Function
Block
82 - 32000
(VL-L)
600(VL-L) System Voltage. This voltage is line to line
unless the system type is 10, where it is line
to neutral. The meter refuses voltages that
are outside of the range of 82-660 volts when
divided by the PT Ratio (above).
cpPhaseLossVolt UCPTphLossVolt
(UCP_Type_9 w/o
resource files)
(SNVT_count ref.)
18 R/W “Meter” Function
Block
1 - 99 (%) 10(%) Phase Loss Voltage Threshold in percent of
system voltage. Any phase (as configured
by nviSystemType) whose level drops below
this threshold triggers a Phase Loss alert.
For example, with the system type set to 40
(3L+N) and the System voltage set to 480V
L-L, the L-N voltage for each phase should
be 277V. When this threshold is set to 10%,
if any phase drops to less than 10% of 277V
(less than 27.7V), or if any L-L voltage drops
to less than 10% of 480V (less than 48V), the
corresponding phase loss alarm bit in nvoAlert
is set to 1.
Configuration Properties
