Veris Industries E50F5A Install - Manual (Page 3)

ZL0119-0A Page 3 of 34 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 09131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
E50F2A, E50F5A
TM
Table of Contents
Dimensions 4
Data Outputs 4
Product Diagram 5
Display Screen Diagram 5
Installation 6
Supported System Types 7
Wiring Symbols 7
Wiring 8
Control Power 9
Quick Setup Instructions 10
Pulse Contact Inputs 10
Solid State Output 11
LON TP/FT-10 Communications 11
User Interface Menu Abbreviations Defined 12
User Interface for Data Configuration 13
Alert/Reset Information 14
User Interface for Setup 15
Resources Available for Downloading 17
Using the LNS Plugin 17
Configuring and Commissioning Without the Plugin 24
Network Variables 25
Configuration Properties 30
Troubleshooting 34
China RoHS Compliance Information 34
