Installation Guide
Power Monitoring
E50F2A, E50F5A
TM
CONTROL POWER
AC 5 VA max.; 90 V min.;
UL Maximum: 600 V
L-L
(347 V
L-N
); CE Maximum: 300 V
L-N
DC* 3 W max.; UL and CE: 125 to 300 VDC
Ride Through Time 100 msec at 120 VAC
INPUT
Pulse Solid-State or mechanical contacts (current less than 1 mA)
Minimum Pulse Width 20 msec
OUTPUT
Alarm Contacts
(E50F2A only)
N.C., static output; (30 VAC/DC, 100 mA max. @ 25°C, derate 0.56 mA per
°C above 25°C)
Communication Port 2-wire, LON TP/FT-10
MECHANICAL CHARACTERISTICS
Weight 0.62 lb (0.28 kg)
IP Degree of Protection (IEC
60529)
IP40 front display; IP20 Meter
Display Characteristics Back-lit blue LCD
Terminal Block Screw Torque 0.37 ft-lb (0.5 N·m) nominal/0.44 ft-lb (0.6 N·m) max.
Terminal Block Wire Size 24 to 14 AWG (0.2 to 2.1 mm2)
Mounting Rail T35 (35mm) DIN Rail per EN50022
OPERATING ENVIRONMENT
Operating Temperature -30° to 70°C (-22° to 158°F)
Storage Temperature -40° to 85°C (-40° to 185°F)
Humidity Range <95% RH (non-condensing)
Altitude of Operation 3 km max.
COMPLIANCE INFORMATION
US and Canada CAT III, Pollution degree 2;
for distribution systems up to 347V
L-N
/600VAC
L-L
CE CAT III, Pollution degree 2;
for distribution systems up to 300V
L-N
Dielectric Withstand Per UL 508, EN61010
Conducted and Radiated
Emissions
FCC part 15 Class B, EN55011/EN61000 Class B (residential and light
industrial)
Conducted and Radiated
Immunity
EN61000 Class A (heavy industrial)
Agencies: US and Canada
(cULus)
UL508 (open type device)/CSA 22.2 No. 14-05
* External DC current limiting is required. See fuse recommendations.
