Installation Guide
Power Monitoring
E50F2A, E50F5A
TM
NV Name
NV
Num.
Function
Block
Type Units
Log
Point
Index
Propagation Control
Description
Configuration
Property
Name
Control
Type
PULSE COUNTERS
nvoPulseCount1
37 Meter SNVT_count_32 - 43 cpPulseCount1 Min Delta Pulse Counter 1 (enabled on E50F2A and E50F5A)
nvoPulseCount2 38 Meter SNVT_count_32 - 45 cpPulseCount2 Min Delta Pulse Counter 2 (enabled on E50F5A only)
nviPulseCntReset 33 Meter SNVT_switch - - - - Clear the pulse counter(s). To reset, set the state field to 1
and the value field to greater than 0.
DIAGNOSTICS
nvoAlert
96 Meter SNVT_state - - cpAlert Heartbeat Diagnostic Alert Bitmap. 1 = Active
Bit 0: Phase A Voltage out of range
Bit 1: Phase B Voltage out of range
Bit 2: Phase C Voltage out of range
Bit 3: Phase A Current out of range
Bit 4: Phase B Current out of range
Bit 5: Phase C Current out of range
Bit 6: Frequency out of the range of 45 to 65 Hz, or
insufficient voltage to determine frequency
Bit 7: Internal data bus communication problem
Bit 8: Phase Loss A
Bit 9: Phase Loss B
Bit 10: Phase Loss C
Bit 11: Low Power Factor on A with one or more phases
having a PF less than 0.5 due to mis-wiring of phases
Bit 12: Low Power Factor on B
Bit 13: Low Power Factor on C
Bit 14: Not used
Bit 15: Not used
nvoStartupCount 94 Meter SNVT_count - - cpStartupCount Heartbeat Power Up Counter.
nvoMeterTime 90 Meter SNVT_time_stamp - - None - Meter Time.
nviTimeSet 7 NodeObject SNVT_time_stamp - - - - Set the Meter Time. Meter time does not have battery
backup and will therefore reset to the millennium
when power is lost to the meter. This input is polled on
startup, and time is restored if this input is bound to a
time source.
nvoMaxSysPower 92 Meter SNVT_power_f W - None - Theoretical Maximum System Power. This value is the
theoretical maximum power the meter expects to see,
based on the System Type, CT size, and System Voltage.
It is updated whenever of these values change.
nvoFullFwVersion 91 Meter SNVT_str_asc - - None Polled Reset System, Operating System, and Gateway revision
numbers in an ascii string (e.g. “RSx.yyy OSx.yyy
Gateway x.yyy”)
Network Variables (cont.)
