Installation Guide
Power Monitoring
E50F2A, E50F5A
TM
NV Name
NV
Num.
Function
Block
Type Units
Log
Point
Index
Propagation Control
Description
Configuration
Property
Name
Control
Type
DEMAND
nvoPresRealDmnd 67
Meter SNVT_power_f W 325 None - Total Real Power Present Demand
nvoPresReactDmnd 68 Meter SNVT_power_f VAR 327 None - Total Reactive Power Present Demand
nvoPresAppDmnd 69 Meter SNVT_power_f VA 329 None - Total Apparent Power Present Demand
nvoMaxRealDmnd 70 Meter SNVT_power_f W 331 None - Total Real Power Max Demand
nvoMaxReactDmnd 71 Meter SNVT_power_f VAR 333 None - Total Reactive Power Max Demand
nvoMaxAppDmnd 72 Meter SNVT_power_f VA 335 None - Total Apparent Power Max Demand
nviDemSubintRes 35 Meter SNVT_power_f - - - - Demand Sub-interval Reset. Begins a new sub-interval
calculation cycle. Takes effect at the end of the next 1
second calculation cycle. To Reset, set the state field to
1 and the value field to greater than 0. Reset no more
frequently than every 10 seconds.
nviMaxDemReset 36 Meter SNVT_power_f - - - - Maximum Demand Reset. Resets maximum demand
values to the present demand. To reset, set the state
field to 1 and the value field to greater than 0. Reset no
more frequently than every 10 seconds.
VOLTAGE
nvoAvgLLVoltage
73 Meter SNVT_volt_f Volt 269 cpAllVoltage Throttle Average Line to Line Voltage
nvoAvgLNVoltage 74 Meter SNVT_volt_f Volt 271 cpAllVoltage Throttle Average Line to Neutral Voltage
nvoLLVoltageAB 75 Meter SNVT_volt_f Volt 287 cpAllVoltage Throttle Line to Line Voltage, Phase A-B
nvoLLVoltageBC 76 Meter SNVT_volt_f Volt 289 cpAllVoltage Throttle Line to Line Voltage, Phase B-C
nvoLLVoltageAC 77 Meter SNVT_volt_f Volt 291 cpAllVoltage Throttle Line to Line Voltage, Phase A-C
nvoLNVoltagePhA 78 Meter SNVT_volt_f Volt 293 cpAllVoltage Throttle Line to Neutral Voltage, Phase A
nvoLNVoltagePhB 79 Meter SNVT_volt_f Volt 295 cpAllVoltage Throttle Line to Neutral Voltage, Phase B
nvoLNVoltagePhC 80 Meter SNVT_volt_f Volt 297 cpAllVoltage Throttle Line to Neutral Voltage, Phase C
CURRENT
nvoAvgCurrent
81 Meter SNVT_amp_f Amp 273 cpAllCurrent Throttle Average Current
nvoCurrentPhA 82 Meter SNVT_amp_f Amp 299 cpAllCurrent Throttle Current, Phase A
nvoCurrentPhB 83 Meter SNVT_amp_f Amp 301 cpAllCurrent Throttle Current, Phase B
nvoCurrentPhC 84 Meter SNVT_amp_f Amp 303 cpAllCurrent Throttle Current, Phase C
POWER FACTOR
nvoAvgPwrFactor
85 Meter SNVT_pwr_fact_f - 267 cpAllPwrFactor Throttle Total Power Factor (Total kW / Total kVA)
nvoPwrFactorPhA 86 Meter SNVT_pwr_fact_f - 281 cpAllPwrFactor Throttle Power Factor, Phase A
nvoPwrFactorPhB 87 Meter SNVT_pwr_fact_f - 283 cpAllPwrFactor Throttle Power Factor, Phase B
nvoPwrFactorPhC 88 Meter SNVT_pwr_fact_f - 285 cpAllPwrFactor Throttle Power Factor, Phase C
FREQUENCY
nvoFrequency
89 Meter SNVT_freq_f Hz 307 cpFrequency Throttle Frequency (derived from Phase A)
Network Variables (cont.)
