8 TECHNICAL DATA
Electro Gas Cooler Version ECP 1000 ECP 2000 ECP 3000
Sample outlet dew point range of adjustment: +2 °C … +15 °C, factory setting: +5 °C
Dew point stability at const. conditions: < ±0,1°C
Sample inlet temperature*** max. 180°C
Sample inlet dew point*** max. 80°C
Gas flow rate/heat exchanger*** 150l/h 150l/h 350l/h
Number of heat exchangers 1 2 1
Material of heat exchangers Duran glass, PVDF or stainless steel 1.4571
Ambient temperature***
+5°C to +45°C*
+5°C to +50°C**
+5°C to +50°C
Storage temperature -20 to +60°C
Pressure
Duran glass : max. 3bar
PVDF : max. 3bar
Stainless steel: max. 10bar (other versions on request)
Total cooling power at +25°C ambient 50KJ/h 90KJ/h
Dead volume/heat exchanger 50cm
3
2 x 50cm
3
100cm
3

P/heat exchanger
1mbar
at 150l/h
1mbar
at 150l/h
5mbar
at 350l/h
Sample gas connection
for Tube 6mm

*
8mm or 10mm

**
G1/4“i
G1/4“i*
NPT**
Condensate connection
for Tube12mm

*
8mm or 10mm

**
G3/8“i
G3/8“i*
NPT**
Ready for operation 10min.
Power consumption 100VA 110VA
Mains power supply 230V or 115V ± 10%, 50...60Hz
Electrical connections Clamps 2,5mm
2
, cable gland 2 x PG11
Alarm contact
2 change-over contacts,
alarm point:

T ± 3°C to T
setting value
Contact rating 250V AC, 2A, 500VA, 50W
Service-measuring point 0,1V/°C
Electrical protection Fuse 2 x 1,6A
T
Case protection IP22 EN 61010
Housing colour RAL 9005 (black)
Method of mounting Wall mounting
Dimension
275mm x 220mm x
136mm
305mm x 220mm x 136mm
Weight 5,5kg 7kg
Electrical equipment standard EN 61010
* Standard
** Option
***
Maximum values in technical datas must be rated in consideration of total cooling capacity at 25 °C ambient
temperature and an outlet dew point of 5 °C.
