13
Gas sampling and gas conditioning technology 3-1.1-ME
N O T E !
When fixing the connectors in the PVDF heat exchanger hold up with a
wrench at the pane of the bolt head!
Option: stainless steel heat exchanger with NPT

The heat exchangers with NPT threaded connectors are marked with circulated notches.

The NPT thread must be screwed in with sealant or fixed with adhesive.
In the standard configuration, the tubes for removal of condensate are connected directly to the heat
exchangers, with the standard GL 25-12 tube connectors (Duran glass heat exchanger) respectively
with the standard G 3/8“ thread joint (PVDF or stainless steel heat exchanger).
Condensate removal is done by customer according to the type of operation with:
- External peristaltic pump SR25.1;
- Automatic float type condensate traps AD-... only for over-pressure operation;
N O T E !
Stainless steel heat exchangers with G 3/8“ thread joint can be
directly fitted up with the float-type condensate trap AD-SS by
means of a thread adapter part number FF 11000
(1/2“ NPT to G
3/8“i). By this wall mounting of the AD-SS unit isn’t necessary!
- Condensate collector container that is emptied manually;
12.2 ELECTRICAL CONNECTIONS
W A R N I N G !
When connecting the equipment, please ensure that the supply
voltage is identical with the information provided on the model type
plate.
N O T E !
Attention must be paid to the requirements of IEC 364 (DIN VDE
0100) when setting high-power electrical units with nominal
voltages of up to 1000 V, together with the associated standards
and stipulations.
Set the voltage selector S1 to the correct mains voltage!
A main switch and matching fuse must be provided externally!
The main circuit is equipped with a fuse corresponding to the
nominal current (over current protection); for electrical details see
technical data.
The main power supply terminals are located in the aluminium enclosure on the ECP .000 electronic
board:

Power On, Terminal X1: 1, 2, 3 / L, N, PE
