Figure 10, Set-up diagram – M&C TechGroup ECP3000 Operator's manual User Manual
Page 26
26
Gas sampling and gas conditioning technology
3-1.1-ME
1
2
3
4
5
6
Pelt.-
Pelt.+
PT100
PT100
Fan -
Fan +
X5
Temperature sensor PT100
**install the sensor with
thermal conductivity
paste
Peltier element
**install with thermal
conductivity paste
Cooling block
Fan
Mains electronic board
Electronic housing
GL 25
Control electronic
board
GL 18
Figure 10
Set-up diagram
