Gas sampling and gas conditioning technology 3-1.1-ME
There are three LED status indicators:

Upper red LED " > °C " = Temperature alarm (T> +8°C)

Central green LED "On", lights or pulsates = Cooler on

Lower red LED " < °C " = Temperature alarm (T< +2°C)
The green LED alone indicates that the specifications with regard to dew point temperature and dew
point stability are achieved. The red LED lights to indicates that the control system has deviated from
the setpoint by more than 3°C. The upper red LED " > °C " lights up to indicate an overload, i.e. more
cooling capacity is being called for than is available. The ECP ..000 Electric Gas Cooler is overload-
protected. In an overload condition the dew point temperature will rise pro-portional to the overload.
An over and under temperature alarm as a status group alarm is available for external indication, via a
relay output with a volt free relay changeover contact. The alarm thresholds are 3°C above and below
the control temperature.
The gas inlet and outlet is located on the top of the cooler and is indicated by arrows on the ECP Jet-
Stream heat exchangers. On standard models with Duran glass heat exchangers the gas connections
are provided with GL18-6 mm PTFE sealing rings and on stainless steel or PVDF exchangers with
G1/4" female threads (or 1/4" NPT as optional).
The condensate drain of the ECP Jet-Stream heat exchangers are located beneath the cooler and
have GL25-12 mm PTFE sealing rings as standard on the Duran glass heat exchangers. And on
stainless steel or PVDF exchangers with G3/8" female threads (or 3/8" NPT as optional).
The type of condensate discharge used will depend on the type of operation:

Peristaltic Pump Type SR25.1 for automatic condensate discharge in vacuum and pressurised
operations.

Automatic Float Condensate Discharge Type AD- .. for pressurised operation only.

Condensate Collection Vessel Type TG../TK.. with manual drain.
10 RECEIPT OF GOODS AND STORAGE
The ECP gas cooler is a complete pre-installed unit.

Please take the ECP gas cooler and possible special accessories carefully out of the packaging
material immediately after arrival, and compare the goods with the items listed on the delivery note!

Check the goods for any damage caused during delivery and, if necessary, notify your transport
insurance company without delay of any damage discovered
N O T E !
The equipment should be stored in a protected, frost-free room!
