12

Gas sampling and gas conditioning technology

3-1.1-ME

11

INSTALLATION INSTRUCTIONS

The ECP .000 Peltier Gas Cooler is designed for wall or panel mounting.

N O T E !

The Cooler is to be used in a vertical position only! The perfect functioning
of the separation and drainage procedures will only be guaranteed if the
equipment is used in a vertical position!

When in use, the ECP cooler should be placed in an area well away from any
heat emitting sources in order to prevent damage caused by an
accumulation of heat the air vents must be free at all times!

When the equipment is being used outside, ample protection against the
effects of direct sunlight and dampness must be provided. In winter, the
equipment must only be used in frost-free areas!

Unheated gas sample lines must be provided with slope up to the cooler. In
that case pre-separation of the condensate is not required.

Connect the heated sample line with sufficient thermal decoupling to the
cooler!



12

SUPPLY CONNECTIONS

12.1

HOSE CONNECTIONS

The gas inlet and outlet is located on the top of the cooler and is indicated by arrows on the ECP Jet-
Stream heat exchangers. For possible connectors see technical data.
Correspondingly tube or hose connectors are optional available by M&C.

N O T E !

Do not mix up the hose connections; the inlet and outlet connections of the
heat exchangers are marked with arrows;

Ensure that the connections are sealed adequately;

To ensure free removal of the condensate, ensure that the listed diameters
for the condensate removsl lines are not reduced!


Ensure that the connections are sealed adequately by noting the following:


Duran glass heat exchangers with connections GL 18-6 respectively GL 25-12

Before assembly, check the GL coupling rings to see if the PTFE/silicon locking rings have been

damaged.

The sealing rings should be installed with the PTFE side facing the medium.


PVDF respectively stainless steel heat exchangers with G 1/4“i respectively G 3/8“i

The correspondingly dimensioned tube respectively hose couplings with threaded connections

have to be screwed in with PTFE thread sealing tape.

To grant a functional and unproblematic mounting we recommend to use union pieces with taper

pipe thread type R according to DIN 2999/1 in connection with suitable sealing tape.
