Gas sampling and gas conditioning technology 3-0.1-ME
17 SPARE PARTS LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and they are not binding.
Electric gas cooler VC-..
(C) Consumable parts
(R) Recommended spare parts
(S) Spare parts
Recommended quantity being in
operation [years]
Part No. Indication C/R/S 1 2 3
02 K 9100 Jet-stream heat exchanger type EC-G. Material: Duran-glass.
Connections: Sample gas: 2x GL18-6mm, Condensate: 1x
GL25-12mm R 1 1
1
90 K 0115 Thermal conductivity paste, -20 to +140°C, silicon free, 50gr. R 1 1 2
90 K 0035 ECP, EC-FD fan 230V 50Hz. C - - 1
91 F 1010 Sealing ring GL18-6mm, material: PTFE. R 2 4 6
91 F 1015 Sealing ring GL18-8mm, material: PTFE. R 2 4 6
91 F 0025 Sealing ring GL25-12mm, material: PTFE. R 2 4 6
91 F 1005 Spare union nut GL18 R 1 1 1
91 F 1007 Spare union nut GL18/14 R 1 1 1
90 F 0020 Spare union nut GL 25 R 1 1 1
90 F 0022 Spare union nut GL 25/18 R 1 1 1
09 F 9500 Connector/adaptor GL18 DN4/6 PV S - - -
09 F 9520 Connector/adaptor GL25 DN4/6 PV. S - - -
09 F 9525 Connector/adaptor GL 25 DN6/8 PV S - - -
09 F 9530 Connector/adaptor GL 25 DN10/12 PV S - - -
Peristaltic pump SR25.1 and SR25.2
(C) Consumable parts
(R) Recommended spare parts
(S) Spare parts
Recommended quantity being in
operation [years]
Part No. Indication C/R/S 1 2 3
90 P 1007 Hose set  SR25.1
with PVDF-tube connectors 4/6mm, standard C 1 2 4
90 P 1020 Driver SR25, complete S - 1 1
90 P 1010 1 set (4 pcs) contact springs SR25 for driver R 1 2 2
90 P 1045 Contact pulleys SR25 PVDF  for driver S 2 4 4
90 P 1050 Conveying belt SR25.1  S - 1 2
90 P 1025 S-bolt  SR25.1 S - - 1
01 P 1000 Peristaltic pump SR25.1, complete 230V/115V, 50/60Hz R - - 1
01 P 1300 Peristaltic pump SR25.2, complete 230V/115V, 50/60Hz R - - 1
90 P 1030 Heat peristaltic pump SR25, complete without motor and gears S - - 1
