Reception and storage, Figure 5, Schematic diagram of the heat exchanger function – M&C TechGroup VC-2-SL Operator's manual User Manual
Page 11
11
Gas sampling and gas conditioning technology
3-0.1-ME
+5°C
Sample
OUT
Sample
IN
Condensate OUT
Cooling
block
Figure 5 Schematic diagram of the heat exchanger function
11
RECEPTION AND STORAGE
The gas cooler VC-.. are complete pre-installed units.
Carefully inspect the cooler and any special accessories included with it immediately on arrival
by removing them from the packing and checking for missing articles against the packing list !
Check the items for any damage in transit and, if required, inform the shipping insurance
company immediately of the damage found!
N O T E !
The cooler must be stored in a weather protected frost-free area!
