35

Gas sampling and gas conditioning technology

9-3.15-ME

25

APPENDIX

Safety handbook according to SIL

Circuit diagram front board PMA50ex 02.2010

Assembly front board PMA50ex 02.2010

Circuit diagram mains adapter PMA50ex 02.2010

Assembly / connection mains adapter PMA 50ex 02.2010

Cut-out magnification front board for adjustment of temperature alarm (TP10, P19) (TP11: ac-

tual temperature) und flow alarm threshold (P20)

Cut-out magnification front board couple sensor bridge for application of a transmitter without

couple sensor

Cut-out magnification front board for adjustment of reference voltage , amplification and offset

of the O2-signal

Cut-out magnification mains adapter for adjustment of the temperature, current and voltage

output

Cut-out magnification mains adapter for adjustment of burden and limitation of the current out-

put

Ex-Certificate of Conformity No.: KEMA 03 ATEX 2215X

SIL-declaration of conformity




Further product documentation can be seen and downloaded from our home page:

www.mc-techgroup.com

.
