8.2.2. Creating and Configuring a Playout Server
To create and configure a playout server, complete the following fields and then click on
the Create button.
The playout server name is added to the list on the left side of the window and “PCX” then
“Channel 1” appear underneath, which corresponds to the playout channel.
Field Description
Label Name you give to the playout server, as it will appear in the list.
Playout Group List of predefined playout groups. The GLOBAL option makes the
playout server available from all Playout Organizer workstations.
IP Address IP address of the playout server.
Port
(default = 4021) Port used for the playout.
Description Optional text to describe the playout server.
Card1 / 2 / 3 Type of card used. Several cards could be used but it is not
advisable.
8.2.3. Modifying the Playout Server Properties
To modify the properties of a playout server, select it in the list, enter new values in the
relevant fields, and click the Update button.
