The XSquare Properties area shows the properties of a XSquare server selected from the
XSquare Servers area.
XSquare Servers configuration
The configuration of XSquare targets can be done manually or automatically.
Automatic Procedure
To automatically find the list of XSquare servers available on the network, proceed as
follows:
1. Click the Discover button.
The XSquare Servers Discovery window opens and lists the XSquare servers found.
2. Select one XSquare server.
3. Click Add.
The properties of the XSquare server are displayed on screen.
4. Click Save.
The selected XSquare server is displayed in the XSquare Servers area.
Manual Procedure
To define a XSquare target manually, proceed as follows:
1. Click New.
The default host name 127.0.0.1 is displayed in the XSquare properties.
2. Set the XSquare properties by completing the fields.
Field Description
DB ID Number automatically allocated by the system when you save the
XSquare configuration.
Label Label given to the machine hosting XSquare (optional).
Host IP address or name of the machine hosting XSquare.
Description Text to describe the XSquare (optional).
3. Click Save.
The selected XSquare server is displayed in the XSquare Servers area.
5.7. Modifying or Deleting an External
Device
To modify the properties of one of the previous external devices, except a switcher, select
it in the list, enter new values in the relevant fields, and click the Update button.
