Item Description
Group Manager Allows to create groups of logical encoders that make logical
channels visible from specific workstations.
Scheduler Displays blocks corresponding to the scheduled ingest already
planned for encoding.
Preview Displays the current video input when the encoder is recording
media.
3.2. Physical Manager
3.2.1. Introduction
You must define and configure a physical encoder before you can use it.
When you click the Physical Manager button, the Physical Encoders Manager window is
displayed in the Work area, allowing you to define or update encoding hardware connected
to the network (Encoder type, IP address) and the encoding parameters.
Contextual menus are available for additional operations.
3.2.2. Creating Physical Encoder
To create and configure a physical encoder, complete the following fields and then click
on the Create button.
