4.3.3. How to Gang Recorder Channels
You can gang several recorder channels from an EVS video server. To do so, proceed as
follows:
1. Select several recorder channels in the I/O Channels area.
2. Right-click the list.
3. Select Gang.
The ganged channels are mentioned in the Ganging column.
4.3.4. Possible Actions with Contextual Menus
A right-click on a server displays a contextual menu with the following option:
Menu Item Description
Delete XT Deletes the selected EVS server from the tree structure.
4.4. EVS Video Server Group
When you click the EVS Video Server Group button, the EVS Video Server Group
Manager window is displayed in the Work area.
To set a group of EVS video server, complete the following fields, select the servers you
want to group and then click on the Create button.
USER MANUAL Xedio 4.35 Xedio Manager
4. LinX and Direct Access 21
