Menu Item Description
New Media Server Adds a media server storage: displays the folders present in
the path selected for use as media server.
Rename Media
Server Allows to update the media server label.
Delete Media Server Deletes the media server view in the Media Servers window.
Modify Media Server
Description Opens the Media Server Modification window allowing to
update the label or description of the media server.
Media File Cleaner Opens the Media File Cleaner window. See section "Media
File Cleaner" on page 130 for more information.
A contextual menu is available when you select a folder in the list and then right-click:
Menu Item Description
New Media Server Adds a media server storage: displays the folders present in
the path selected for use as media server.
Default "Folder Name
Files" Directory Sets the selected folder as default folder for the type of files
(bitmaps, video files, thumbnails etc…). The folder icon is then
green.
This is only necessary when multiple storage servers are
created in the system. This tells the system to use a specific
storage server for some files and another server for other files.
The Default folders may be changed at any time without losing
previously stored material.
Example: for the HIRES folder, the option is Default
"HiResFiles" Directory and sets the HIRES folder as default
for the hi-res files.
Delete Media
Directory Removes the media folder from the Media Servers window.
Collect Media Displays the list of media present in the selected folder.
Media File Cleaner Opens the Media File Cleaner window. See section "Media
File Cleaner" on page 130 for more information.
6.2.4. Setting the CDM Encoder Mapped Drive
The physical encoder is usually configured to store the encoded files on a specific
mapped drive, usually called “G” or “H”. This mapped drive letter also has to be stored in
the database in the CDM Mapping column.
To set or change the encoder mapped drive, proceed as follows:
1. In the Medias Servers window, click twice (not a double click, click then wait and click
again) the mapped drive letter related to the requested server in the CDM mapping
column.
34 6. Media
EVS Broadcast Equipment SA Issue 4.35.B - August 2013
