3.4.2. Creating a Group of Logical Channels
To create a group of logical encoders, complete the following fields and then click on the
Create button.
The group name is added to the list on the left side of the window.
Field Description
Label Give a name to the group of logical encoder.
Description Optional text to describe the group of logical encoders.
Logical Encoders Select the logical encoders to group together.
Note
A group of logical channels restricts the amount of available channels for
specific Xedio Ingest Organizer workstations. There is one default group, called
GLOBAL, that allows a Xedio Ingest Organizer workstation to “see” all
channels when it is selected.
Note
To finalize encoders configuration, it is necessary to store the CDM encoders
mapped drive in the database. See section "Setting the CDM Encoder Mapped
Drive" on page 34.
16 3. Encoders
EVS Broadcast Equipment SA Issue 4.35.B - August 2013
