Area Description
The table below describes the various parts of the Xedio Manager window:
Part Name Description
1. Menu bar The menu bar gives access to general commands and to
configuration parameters.
See section "Menu Bar" on page 3.
2. Outlook bar The Outlook bar presents nine tabs corresponding to the areas
managed by Xedio Manager.
See section "The Outlook Bar" on page 5.
3. Work area The Work area is only active when an item is selected in one
category from the Outlook area. Thus, the window displayed in
the Work area depends on the selected item. Parameters are
set from this area.
See sections "Encoders" on page 7 to "Users" on page 125.
4. Logbook area The Logbook area lists the operations that the user performs in
the database and their status. If a problem occurs, an error
message is added in the list. At the same time, the application
saves all this information in a log file.
2.2. Menu Bar
2.2.1. Tools Menu
The Tools menu gives access to the Media File Cleaner tool. This tool shows the list of all
the media files present on the Xedio media servers but not referenced in the database
(orphan files). From the Media File Cleaner window, it is possible to delete these orphan
files. See section "Media File Cleaner" on page 130 for more information.
2.2.2. View Menu
The View menu provides the following options:
Menu Item Description
Outlook Bar Displays or hides the Outlook bar.
Logbook Bar Displays or hides the Logbook bar.
Full Screen Hides the Menu bar.
