Area Description
Xsquare is made up of the following modules:
# Module Task
1. Job Initiators Allows users to configure, start or stop different
systems that initiate jobs the processing devices will
manage.
See section "Job Initiators" on page 5
2. Configuration The Configuration section contains configurable
elements in Xsquare:
• The Orchestration tool allows users to group the
processing devices in clusters dedicated to
specific job types. This makes it possible to
distribute the jobs more efficiently among the
various processing devices.
See section "Orchestration" on page 24
• The Job Templates tool allows users to create
customized job templates based on the
predefined job templates available by default in
Xsquare.
See section "Managing Templates and Profiles"
on page 38
• The Encoders /Wrappers Profiles tool allows
users to customize encoder / wrapper profiles
based on the predefined ones available by default
in Xsquare.
See section "Managing Templates and Profiles"
on page 38
• The Icons Manager tool allows managing the
icons used in Xsquare.
See section "Icons Manager" on page 49
3. Monitoring Allows users to monitor:
• the jobs scheduled, or already processed by the
processing devices.
• the EVS servers detected on the network.
See section "Monitoring" on page 53
4. Administration Allows users to define user rights to access Xsquare.
See section "Users and Access" on page 50
Note
A separate association tool makes it possible associate XTAccess applications
installed on the network to Xsquare. Such associations are logically (but not
necessarily) done before you start using Xsquare. See the documentation
specific to this tool for more information.
