P-334WHD User’s Guide
Chapter 3 Connection Wizard 63
The following table describes the fields in this screen.
Table 20 Wizard Step 3: Modem Dial-up Connection
LABEL DESCRIPTION
ISP Parameters for Internet Access
Connection Type Select Only Modem Dial Up for a WAN dial-up connection via the built-in
modem.
Login Name Type the login name given to you by your ISP.
Password Type the password associated with the user name above.
Phone Number Type the phone number from the ISP for this dial-up connection.
Back Click Back to return to the previous screen.
Next Click Next to continue.
Exit Click Exit to close the wizard screen without saving.
3.4.5 Your IP Address
The following wizard screen allows you to assign a fixed IP address or give the ZyXEL
Device an automatically assigned IP address depending on your ISP.
Figure 27 Wizard Step 3: Your IP Address
The following table describes the labels in this screen.
Table 21 Wizard Step 3: Your IP Address
LABEL DESCRIPTION
Get automatically from
your ISP
Select this option If your ISP did not assign you a fixed IP address. This is
the default selection. If you choose this option, skip directly to section 3.4.8 .
Use fixed IP address
provided by your ISP
Select this option if you were given IP address and/or DNS server settings
by the ISP. The fixed IP address should be in the same subnet as your
broadband modem or router.
Back Click Back to return to the previous screen.
Next Click Next to continue.
Exit Click Exit to close the wizard screen without saving.
