Page 45
P-334WHD User’s Guide
Chapter 2 Introducing the Web Configurator
45
2.4.4 Navigation Panel
After you enter the password, use the sub-menus on the navigation panel to configure ZyXEL
Device features.
The following table lists the features available for each operating mode.
Interface Status
Interface
This displays the ZyXEL Device port types.
Status
For the LAN ports, this field displays Down (line is down) or Up (line is up or
connected).
For the WiFi WAN, it displays Up when the WiFi WAN is enabled or Down when the
WiFi WAN is disabled.
Rate
For the LAN ports, this displays the port speed and duplex setting or N/A when the
line is disconnected.
For the WiFi WAN, it displays the connection type (54M) when the WiFi WAN is
enabled and N/A when the WiFi WAN is disabled.
Summary
BW MGNT Monitor
Use this screen to view the ZyXEL Device’s bandwidth usage and allotments.
DHCP Table
Use this screen to view current DHCP client information.
Packet Statistics
Use this screen to view port status and packet specific statistics.
Table 7 Web Configurator Status Screen (WiFi WAN Router Mode) (continued)
LABEL
DESCRIPTION
Table 8 Router, AP and WiFi WAN Router Mode Features Comparison
FEATURE
ROUTER MODE
ACCESS POINT
MODE
WIFI WAN ROUTER
MODE
Connection Wizard
O
Bandwidth Management Monitor
O
O
DHCP Table
O
O
Packet Statistics
O
O
O
WLAN Station Status
O
O
Wireless LAN
O
O
WAN
O
Modem Dial-up
O
WiFi WAN
O
LAN
O
O
O
DHCP Server
O
O
NAT
O
O
DDNS
O
O
Firewall
O
O
Content Filter
O
O
Static Route
O
O
