P-334WHD User’s Guide
Chapter 2 Introducing the Web Configurator 39
System Uptime This is the total time the ZyXEL Device has been on.
Current Date/Time This field displays your ZyXEL Device’s present date and time.
System Resource
- CPU Usage This displays what percentage of the ZyXEL Device’s processing ability is currently
used. When this percentage is close to 100%, the ZyXEL Device is running at full
load, and the throughput is not going to improve anymore. If you want some
applications to have more throughput, you should turn off other applications (for
example, using bandwidth management.
- Memory Usage This shows what percentage of the heap memory the ZyXEL Device is using. Heap
memory refers to the memory that is not used by ZyNOS (ZyXEL Network Operating
System) and is thus available for running processes like NAT and the firewall.
System Setting
- Firewall This shows whether the firewall is active or not.
- Bandwidth Management This shows whether the bandwidth management is active or not.
- UPnP This shows whether UPnP is active or not.
- Configuration Mode This shows whether the advanced screens of each feature are turned on (Advanced)
or not (Basic).
- System Operation Mode This shows whether the ZyXEL Device is working as a router, access point or WiFi
WAN router.
Interface Status
Interface This displays the ZyXEL Device port types.
Status For the LAN and WAN ports, this field displays Down (line is down) or Up (line is up
or connected).
For the WLAN, it displays Up when the WLAN is enabled or Down when the WLAN is
disabled.
For the WAN dial-up connection, it displays Idle when the modem dialup is enabled
but the line is not up, Up when the dial-up connection is up, Dial when the ZyXEL
Device is triggering a call or Down when the modem dialup is disabled.
Rate For the LAN ports, this displays the port speed and duplex setting or N/A when the
line is disconnected.
For the WAN port, it displays the port speed and duplex setting if you’re using
Ethernet encapsulation and Idle (line (ppp) idle), Dial (starting to trigger a call) and
Drop (dropping a call) if you're using PPPoE or PPTP encapsulation. This field
displays N/A when the line is disconnected.
For the WLAN, it displays the connection type (54M or 11M) when the WLAN is
enabled and N/A when the WLAN is disabled.
For the WAN dial-up connection, it displays the connection type (56K) when the line
is up. This field displays N/A when the line is down.
Summary
BW MGNT Monitor Use this screen to view the ZyXEL Device’s bandwidth usage and allotments.
DHCP Table Use this screen to view current DHCP client information.
Packet Statistics Use this screen to view port status and packet specific statistics.
WLAN Station Status Use this screen to view the wireless stations that are currently associated to the
ZyXEL Device.
Table 3 Web Configurator Status Screen (Router Mode) (continued)
LABEL DESCRIPTION
