Table 1 led descriptions – ZyXEL Communications P-334WHD User Manual
Page 33
P-334WHD User’s Guide
Chapter 1 Getting to Know Your ZyXEL Device
33
The following table describes the LEDs on the ZyXEL Device.
Table 1 LED Descriptions
LED
COLOR
STATUS
DESCRIPTION
PWR
Green
On
The ZyXEL Device is receiving power and functioning
properly.
Blinking
The ZyXEL Device is performing testing.
Red
On
Power to the ZyXEL Device is too low.
None
Off
The ZyXEL Device is not receiving power.
LAN 1-4
Green
On
The ZyXEL Device has a successful 10Mb Ethernet
connection.
Blinking
The ZyXEL Device is sending/receiving data.
Amber
On
The ZyXEL Device has a successful 100Mb Ethernet
connection.
Blinking
The ZyXEL Device is sending/receiving data.
None
Off
The LAN is not connected.
WAN
Green
On
The ZyXEL Device has a successful 10Mb WAN
connection.
Blinking
The ZyXEL Device is sending/receiving data.
Amber
On
The ZyXEL Device has a successful 100Mb Ethernet
connection.
Blinking
The ZyXEL Device is sending/receiving data.
None
Off
The WAN connection is not ready, or has failed.
MODE
Green
On
The ZyXEL Device is in WiFi WAN router mode.
Amber
On
The ZyXEL Device is in access point mode.
None
Off
The ZyXEL Device is in router mode.
WLAN
Green
On
The ZyXEL Device is ready, but is not sending/receiving
data through the wireless LAN.
Blinking
The ZyXEL Device is sending/receiving data through the
wireless LAN.
None
Off
The wireless LAN is not ready or has failed.
MODEM
Green
Blinking
The ZyXEL Device is sending/receiving data through the
modem. The telephone connected to the ZyXEL Device
cannot be in use.
None
Off
The dial-up connection is not in use or the modem is not
ready.
