P-334WHD User’s Guide
44 Chapter 2 Introducing the Web Configurator
The following table describes the labels shown in the Status screen.
Table 7 Web Configurator Status Screen (WiFi WAN Router Mode)
LABEL DESCRIPTION
Device Information
System Name This is the System Name you enter in the Maintenance > System > General
screen. It is for identification purposes.
Firmware Version This is the ZyNOS firmware version and the date created. ZyNOS is ZyXEL's
proprietary Network Operating System design.
LAN Information
- MAC Address This shows the LAN Ethernet adapter MAC Address of your device.
- IP Address This shows the LAN port’s IP address.
- IP Subnet Mask This shows the LAN port’s subnet mask.
- DHCP This shows the LAN port’s DHCP role - Server, Relay or None.
WiFi WAN Information
- MAC Address This shows the wireless adapter MAC Address of your device.
- IP Address This shows the WiFi WAN IP address obtained from an AP or wireless router.
- IP Subnet Mask This shows the WiFi WAN subnet mask obtained from an AP or wireless router.
- DHCP This shows the WiFi WAN port’s DHCP role - Client or None.
- Name(SSID) This shows a descriptive name used to identify the ZyXEL Device in the wireless
LAN.
- Channel This shows the channel number which the ZyXEL Device is currently using. This
displays Unknow when the ZyXEL Device is not connected to a wireless network.
- Security Mode This shows the level of wireless security the ZyXEL Device is using.
- 802.11 Mode This shows the wireless standard.
System Status
System Uptime This is the total time the ZyXEL Device has been on.
Current Date/Time This field displays your ZyXEL Device’s present date and time.
System Resource
- CPU Usage This displays what percentage of the ZyXEL Device’s processing ability is currently
used. When this percentage is close to 100%, the ZyXEL Device is running at full
load, and the throughput is not going to improve anymore. If you want some
applications to have more throughput, you should turn off other applications (for
example, using bandwidth management.
- Memory Usage This shows what percentage of the heap memory the ZyXEL Device is using. Heap
memory refers to the memory that is not used by ZyNOS (ZyXEL Network Operating
System) and is thus available for running processes like NAT and the firewall.
System Setting
- Firewall This shows whether the firewall is active or not.
- Bandwidth Management This shows whether the bandwidth management is active or not.
- UPnP This shows whether UPnP is active or not.
- Configuration Mode This shows whether the advanced screens of each feature are turned on (Advanced)
or not (Basic).
- System Operation Mode This shows whether the ZyXEL Device is working as a router, access point or WiFi
WAN router.
