P-334WHD User’s Guide
42 Chapter 2 Introducing the Web Configurator
2.4.3 WiFi WAN Router Mode Status
The following screen displays when the ZyXEL Device is set to WiFi WAN router mode.
- Configuration Mode This shows whether the advanced screens of each feature are turned on (Advanced)
or not (Basic).
- System Operation Mode This shows whether the ZyXEL Device is working as a router, access point or WiFi
WAN router.
Interface Status
Interface This displays the ZyXEL Device port types.
Status For the LAN ports, this field displays Down (line is down) or Up (line is up or
connected).
For the WLAN, it displays Up when the WLAN is enabled or Down when the WLAN is
disabled.
Rate For the LAN ports, this displays the port speed and duplex setting or N/A when the
line is disconnected.
For the WLAN, it displays the connection type (54M or 11M) when the WLAN is
enabled and N/A when the WLAN is disabled.
Summary
Packet Statistics Use this screen to view port status and packet specific statistics.
WLAN Station Status Use this screen to view the wireless stations that are currently associated to the
ZyXEL Device.
Table 5 Web Configurator Status Screen (AP Mode) (continued)
LABEL DESCRIPTION
