P-334WHD User’s Guide
38
Chapter 2 Introducing the Web Configurator
The following table describes the labels shown in the Status screen.
Select a number of seconds or None from the drop-down list box to refresh all screen
statistics automatically at the end of every time interval or to not refresh the screen
statistics.
Click this button to refresh the status screen statistics.
Table 2 Status Screen Icon Key (continued)
ICON
DESCRIPTION
Table 3 Web Configurator Status Screen (Router Mode)
LABEL
DESCRIPTION
Device Information
System Name
This is the System Name you enter in the Maintenance > System > General
screen. It is for identification purposes.
Firmware Version
This is the ZyNOS firmware version and the date created. ZyNOS is ZyXEL's
proprietary Network Operating System design.
WAN Information
- MAC Address
This shows the WAN Ethernet adapter MAC Address of your device.
- IP Address
This shows the WAN port’s IP address.
- IP Subnet Mask
This shows the WAN port’s subnet mask.
- DHCP
This shows the WAN port’s DHCP role - Client or None.
LAN Information
- MAC Address
This shows the LAN Ethernet adapter MAC Address of your device.
- IP Address
This shows the LAN port’s IP address.
- IP Subnet Mask
This shows the LAN port’s subnet mask.
- DHCP
This shows the LAN port’s DHCP role - Server, Relay or None.
WLAN Information
- MAC Address
This shows the wireless adapter MAC Address of your device.
- Name(SSID)
This shows a descriptive name used to identify the ZyXEL Device in the wireless
LAN.
- Channel
This shows the channel number which you select manually or the ZyXEL Device
automatically scans and selects.
- Operating Channel
This shows the channel number which the ZyXEL Device is currently using over the
wireless LAN. This displays Disabled when the WLAN is disabled.
- Security Mode
This shows the level of wireless security the ZyXEL Device is using.
- 802.11 Mode
This shows the wireless standard.
Dialup Information
- IP Address
This shows the IP address that the ISP gave you for the dial-up connection.
- IP Subnet Mask
This shows the subnet mask that the ISP gave you for the dial-up connection.
- IP Assignment
This shows whether the IP address is assigned automatically by the ISP (Dynamic)
or entered manually (Static) in the WAN > Modem Dialup screen.
System Status
