Prestige 2602R Series User’s Guide
342 Chapter 36 IP Policy Routing
3 Create a rule in menu 25.1 for this set to route packets from any host ( IP=0.0.0.0
means any host) with protocol TCP and port FTP access through another gateway
(192.168.1.100).
Figure 215 IP Routing Policy Example
4 Check Menu 25.1 — IP Routing Policy Setup to see if the rule is added correctly.
5 Apply both policy sets in menu 3.2 as shown next.
Figure 216 Applying IP Policies Example
Menu 25.1.1 - IP Routing Policy
Policy Set Name= 2
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Don't Care Packet length= 10
Precedence = Don't Care Len Comp= Equal
Source:
addr start= 0.0.0.0 end= N/A
port start= 0 end= N/A
Destination:
addr start= 0.0.0.0 end= N/A
port start= 20 end= 21
Action= Matched
Gateway type = Gateway addr Gateway addr = 192.168.1.100
Type of Service= No Change Gateway node = 0
Precedence = No Change Log= No
Press ENTER to Confirm or ESC to Cancel:
Menu 3.2 - TCP/IP and DHCP Ethernet Setup
DHCP Setup
DHCP= Server
Client IP Pool Starting Address= 192.168.1.33
Size of Client IP Pool= 64
Primary DNS Server= 0.0.0.0
Secondary DNS Server= 0.0.0.0
Remote DHCP Server= N/A
TCP/IP Setup:
IP Address= 192.168.1.1
IP Subnet Mask= 255.255.255.0
RIP Direction= Both
Version= RIP-1
Multicast= None
IP Policies= 1,2
Edit IP Alias= No
Press ENTER to Confirm or ESC to Cancel:
