Prestige 643 ADSL Router
Bridging Setup 7-3
Step 1. In Menu 11.1, set the Bridge field to Yes.
Step 2. Move the cursor to the Edit IP/IPX/Bridge field, press [SPACE BAR] to choose Yes and
press [ENTER] to display Menu 11.3 – Remote Node Network Layer Options.
Figure 7-2 Menu 11.3 - Remote Node Network Layer Options
The following table describes the bridging-dependent parameters in the Remote Node Profile and Network
Layers menus.
Table 7-2 Remote Node Network Layer Options
FIELD DESCRIPTION
Bridge
(Menu 11.1) Make sure this field is set to Yes.
Edit IP/IPX/Bridge
(Menu 11.1) Press [ SPACE BAR ] to change it to Yes and press [ ENTER ] to go to the
Remote Node Network Layer Options menu.
Menu 11.3 - Remote Node Network Layer Options
VPI/VCI (LLC-mux or PPP/PPPoE Encap):
VPI #= 0
VCI #= 35
IP Options:
Rem IP Addr: 0.0.0.0
Rem Subnet Mask= 0.0.0.0
My WAN Addr= 0.0.0.0
Single User Account= Yes
Metric= 2
Private= No
RIP Direction= None
Version= RIP-1
Multicast= None
IP Policies=
IPX Options:
Rem LAN Net #= N/A
My WAN Net #= N/A
Hop Count= N/A
Tick Count= N/A
W/D Spoofing(min)= N/A
SAP/RIP Timeout(min)= N/A
Dial-On-Query= N/A
Bridge Options:
Dial-On-Broadcast= No
Ethernet Addr Timeout(min)= 0
Enter here to CONFIRM or ESC to CANCEL:
