Prestige 643 ADSL Router
10-2 System Maintenance
The table below describes the fields present in Menu 24.1 - System Maintenance - Status. Note that these
fields are READ-ONLY and are meant to be used for diagnostic purposes.
Note: Displaying this screen degrades system performance.
Figure 10-2 Menu 24.1 - System Maintenance - Status
The following table describes the fields present in Menu 24.1 - System Maintenance – Status:
Table 10-1 System Maintenance - Status Menu Fields
FIELD DESCRIPTION
This is the remote node index number and link type. Link types are Node-Lnk
PPP, ENET, 1483 or PPPoE
Status Shows the status of the remote node.
TxPkts The number of packets transmitted to this remote node.
Menu 24.1 -- System Maintenance – Status
Node-Lnk
1-1483
2
3
4
5
6
7
8
Status
Up
N/A
N/A
N/A
N/A
N/A
N/A
N/A
TxPkts
1462
0
0
0
0
0
0
0
RxPkts
1567
0
0
0
0
0
0
0
Errors
0
0
0
0
0
0
0
0
Tx B/s
222
0
0
0
0
0
0
0
Rx B/s
211
0
0
0
0
0
0
0
Up Time
2:15:16
0:00:00
0:00:00
0:00:00
0:00:00
0:00:00
0:00:00
0:00:00
Ethernet:
Status: 100M/Full Duplex
Collisions: 0
Tx Pkts: 1583
Rx Pkts: 1521
WAN:
Line Status: Up
Upstream Speed: 608 kbps
Downstream Speed: 4000 kbps
CPU Load = 4.25%
Press Command:
COMMANDS: 1-Reset Counters ESC-Exit
