8-20 Filter Configuration
Figure 8-15 Example Filter Rules Summary - Menu 21.3
After you’ve created the filter set, you must apply it.
Step 1. Enter 11 from the main menu to display Menu 11.
Step 2. Go to the Edit Filter Sets field. Press [SPACE BAR] to change No to Yes and press
[ENTER] to display Menu 11.5.
Step 3. Apply the TELNET_WAN filter set (filter set 3) as shown in the Filtering Remote Node Traffic
(PPPoE Encapsulation) figure.
Step 4. Press [ENTER] to confirm after you enter the set numbers and to leave Menu 11.5.
Menu 21.3 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- --------------------------------------------------------------- - - -
1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=23 N D F
2 N
3 N
4 N
5 N
6 N
This shows you that you have
configured and activated (A = Y) a
TCP/IP filter rule (Type = IP, Pr = 6)
for destination telnet ports (DP =
23).
M = N means an action can be taken immediately.
The action is to drop the packet (m = D) if the
action is matched and to forward the packet
immediately (n = F) if the action is not matched no
matter whether there are more rules to be
checked (there aren’t in this example).
