Prestige 643 ADSL Router
Remote Node Configuration 4-7
4.1.5 Remote Node Filter
In Menu 11.1 – Remote Node Profile make sure the Edit Filter Sets field displays Yes by pressing the
[SPACE BAR]. Press [ENTER] to access Menu 11.5 – Remote Node Filter.
Use Menu 11.5 – Remote Node Filter to specify the filter set(s) to apply to the incoming and outgoing
traffic between this remote node and the Prestige. You can specify up to 4 filter sets separated by commas,
eg. 1, 5, 9, 12 in each filter field. For more information on defining the filters, see the Filter Configuration
chapter. Note that there are two versions of this menu depending on whether you use PPPoE encapsulation
or not. When using PPPoE encapsulation, you can also specify remote nodes called filter sets.
Figure 4-4 Menu 11.5 - Remote Node Filter
Figure 4-5 Menu 11.5 - Remote Node Filter (PPPoE Encapsulation)
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
Menu 11.5 - Remote Node Filter Options
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Call Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
