Wa t l o w E Z - Z O N E ® P M I n t e g r a t e d C o n t r o l l e r • 4 9 • C h a p t e r 8 F a c t o r y P a g e
To go to the Factory Page from the Home Page,
press and hold both the Advance
‰ and Infinity ˆ
keys for six seconds.
• Press the Advance Key ‰ to move through the
parameter prompts.
• Press the Up ¿ or Down ¯ keys to change the
parameter value.
• Press the Infinity Key ˆ to return to the Home
Page.
Note: Avoid continuous writes within loops. Excessive writes to
EEPROM will cause premature EEPROM failure. The EEPROM
is rated for 1,000,000 writes.
Chapter 8: Factory Page
Home
Page
Factory Page Parameters
[~~p~] ˆ
[~~Sp] ‰ˆ
[CUST] ˆ
[FCty] ‰
[```I] ˆ
[CUST] ‰ [`PAr] ‰ [`iid] ‰
Hold both keys
for 6 seconds.
Custom
Menu
<
>
Custom 1
Submenu Parameter Instance
ˆ Custom 2
to 20
Submenus
Same as above.
ˆ [`LoC] ˆ
[FCty] ‰ [LoC;o] ‰ [LoC;P] ‰ [rLoC] ‰ [SLoC] ‰
Lockout
Menu
<
>
Lock
Operations
Page Lock
Profi ling
Page Read Lock Set Lock
ˆ [diAg] ˆ
[FCty] ‰ [``Pn] ‰ [`rEu] ‰ [S;bLd] ‰ [``Sn] ‰ [dAtE] ‰ [USr;r] ‰ [USr;S] ‰ [iP;A1] … [iP;A4] ‰ [C;LEd] ‰
Diagnostic
Menu
<
>
Part Number Software
Revision
Software
Build Serial
Number Date of
Manufacture User Restore
Set User Save
Set IP Actual
Address
Part 1 IP Actual
Address
Part 4 Communica-
tions Indica-
tor Light
ˆ [`CAL] ˆ
[FCty] ‰
[~~~I] ˆ
[`CAl] ‰ [`Mu] ‰ [ELi;o] ‰ [ELi;S] ‰ [ELo;o] ‰ [ELo;S] ‰
Calibration
Menu
<
>
Calibration 1
Submenu
<
>
Electrical
Measure-
ment Electrical
Input Offset Electrical
Input Slope Electrical
Output
Offset Electrical
Output Slope
ˆ Calibration 2
Submenu
Same as above.
Navigating the Factory Page
Note:
Some of these menus and parameters may
not appear, depending on the controller's
options. See model number information in
the Appendix for more information.
If there is only one instance of a menu, no
submenus will appear.
