50 Running the Library
Removing the Magazine from the Unit
The following illustration shows the correct way to remove the magazine from its bay.
Note
You cannot remove the magazine if the unit is password protected or locked by
host software through a Prevent Medium Removal SCSI command.
When ejecting the magazine it automatically pops out a few inches. With one hand, grip the handle on
the outer side of the magazine bezel and hold the other hand under the magazine. Pull the magazine
carefully out and keep it in level with the library. If the magazine is filled with cartridges, be aware of
the weight of the magazine. Keep one hand underneath the magazine to prevent the back of the
magazine to fall down when it leaves the magazine bay. See
Figure 18. Removing the Magazine from
the Library.
Figure 18. Removing the Magazine from the Library
Inserting Cartridges into the Magazine
When inserting cartridges, the access door of the cartridge must face the magazine slot opening.
Push the cartridge carefully into the magazine slot until it locks in place. The rear side of the cartridge
with the Write Protect switch and the barcode label must face out. Make sure the cartridges latch
properly.
Figure 19. Gently Push the Cartridge into the Magazine Slot
Removing Cartridges from the Magazine
Press the cartridge release tab towards the cartridge until the cartridge is released. The cartridge is
spring loaded, so it is important to prevent the cartridge from popping all the way out.
