StorageLibrary Installation and User Guide

11

4

Installing the Library

This chapter provides detailed information for installing the library hardware. For basic library cabling
instructions, refer to the

Quick Installation Guide.

Remove the Transport Locking Screws

To protect the library during transport, four transport locking screws hold the robotics in a locked
position. The screws are marked with red plastic tabs protruding between the magazines and the front
panel.

Caution

The transport locking screws must be removed before the StorageLibrary can
operate normally.

Figure 3. Transport Locking Screws Marked with Red Plastic Tabs

The transport locking screws will be detected when the StorageLibrary is powered on. To remove the
screws follow the instructions below:

1 Connect the power cord to the power connector on the rear of the library.

2 Turn on the power switch on the rear of the library.

3 The library detects that the transport locking screws are present. Follow the instructions on the

front panel display to remove the magazines to get access to the screws. Remove the screws and
reinsert the magazines.
