16 Installing the Library
Figure 10. StorageLibrary Mounted in a Rack, Rear View
The figure above gives a rear-end view of the StorageLibrary mounted in a rack. The two screws on
each side connect the left and right rail assemblies to the rack.
Installing the Library
After mounting, you must connect the cables to the library. Two sets of cabling instructions are
available:
For libraries with SCSI tape drives
For libraries with Fibre Channel tape drives
For instructions on cabling a library with SCSI tape drives, see Connecting Library Cables (SCSI) .
For instructions on cabling a library with Fibre Channel tape drives, see Connecting Library Cables
(Fibre Channel) .
If your library includes both SCSI and Fibre Channel tape drives, cable the tape drive following the
appropriate instructions for that tape drive type.
Connecting Library Cables (SCSI)
Use this procedure if you are installing a library that includes SCSI tape drives.
Figure 11. StorageLibrary Cabling (SCSI)
