Dimensions
CRCB
01 - Double [intake / exhaust] Centrifugal fan
02 - Terminal box
03 - Service panel
04 - Motor
05 - Condensing coil
06 - Spacing for ø 27 energy intake wire
07 - Refrigeration connections (only one setting)
Model
A
B
C
D
E
F
G
H
I
J
L
M
N
P
Q
R
ø L1
ø D1
ø L2
ø D2
050
39
25
35
12
16
–
–
13
30
28
4
41
21
5
–
–
1/2”
5/8”
–
–
(987)
(631)
(890) (295.5) (396)
(341)
(762)
(711) (110)
(1029)
(521)
(132)
075
49
25
35
17
16
–
–
13
40
32
4
51
21
5
–
–
1/2”
3/4”
–
–
(1241)
(631)
(890) (422.5) (396)
(341) (1016) (816.5) (110)
(1283)
(521)
(132)
100
49
25
37
9
13
9
13
11
45
34
4
55
21
6
8
10
1/2”
5/8”
1/2”
5/8”
(1341)
(631)
(941) (212.5) (333)
(230)
(333)
(289) (1143) (863.5) (97)
(1383)
(521)
(159)
(200)
(255)
125
65
28
40
12
16
10
16
13
58
37
3
67
24
9
8
10
1/2”
3/4”
1/2”
5/8”
(1646)
(714)
(1018) (299.5) (396)
(255)
(396)
(341) (1473)
(940)
(84)
(1688)
(604)
(236)
(200)
(255)
150
65
28
49
12
16
10
16
13
58
46
3
67
24
9
8
10
1/2”
3/4”
1/2”
5/8”
(1646)
(714)
(1247) (299.5) (396)
(255)
(396)
(341) (1473)
(1168) (84)
(1688)
(604)
(236)
(200)
(255)
All dimensions are in
