PKG-PRC007-EN 14
Performance
Data Fan
Data
Table PD-4 — Fan Performance SRVE/SIVE/SAVE 12.5 Tons
External static pressure with permanent air filter inches of water (Pa)
.08 .16 .24 .31 .39 .50 .63
Model Airflow (19.9) (39.8) (59.8) (77.2) (97.1) (124.5) (156.9)
Option 12.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4505 7650 630 0.81 666 0.89 701 0.98 735 1.08 768 1.18 800 1.29 8.61 1.50
MT 2.0 CV 4694 7970 649 0.93 684 1.01 718 1.09 751 1.18 783 1.27 814 1.37
MS: 78,5 A 106,5 4882 8290 670 1.04 703 1.12 736 1.20 768 1.29 799 1.39 830 1.49
STD BS: 184 (8") 5069 8608 690 1.15 723 1.24 754 1.32 785 1.41 816 1.51 845 1.61
B: 1X A33 5256 8925 711 1.28 743 1.37 774 1.46 804 1.55 833 1.65 862 1.75
5445 9243 731 1.41 762 1.50 792 1.60 821 1.69 850 1.79
5630 9560 753 1.56 783 1.65 812 1.75 841 1.85
External static pressure with permanent air filter inches of water (Pa)
.39 .50 .63 .79 .94 1.10
Model Airflow (97.1) (124.5) (156.9) (195.7) (234.1) (273.9)
Option 12.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4505 7650 919 1.62 975 1.88 1029 2.06
MT 3.0 CV 4694 7970 874 1.57 931 1.79 985 2.00 1038 2.23
MS: 79 A 105 4882 8290 888 1.69 944 1.91 997 2.13 1049 2.35
OP1 FS: 169 (7") 5069 8608 902 1.82 957 2.04 1010 2.26 1060 2.48
B: 1X B32 5256 8925 918 1.97 971 2.18 1023 2.40
5445 9243 878 1.90 932 2.11 985 2.33 1035 2.55
5630 9560 868 1.95 896 2.06 949 2.27 1000 2.49
External static pressure with permanent air filter inches of water (Pa)
.94 1.10 1.26 1.42 1.57
Model Airflow (234.1) (273.9) (313.7) (353.6) (390.9)
Option 12.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4505 7650 1081 2.26 1131 2.52 1179 2.73
MT 4.0 CV 4694 7970 1089 2.44 1139 2.65 1187 2.81
MS: 79 A 105 4882 8290 1099 2.56 1148 2.77 1195 2.92
OP2 FS: 143 (6") 5069 8608 1109 2.69 1156 2.89 1203 3.13
B: 1X B29 5256 8925 1073 2.62 1121 2.84 1167 2.95 1213 3.20
5445 9243 1084 2.77 1131 2.98 1177 3.10
5630 9560 1050 2.71 1098 2.93 1144 3.15 1189 3.30
MT = Motor (CV).
MS = Motor Sheave, variable pitch (mm).
FS = Fan Sheave (mm).
B
= Belt.
