Table PD-15 — Gross Cooling Capacities SRVE-150
English
Ambient Temperature (°F)
85
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(ºF)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
75
161.0
135.9
179.6
102.9
199.5
69.6
155.3
133.2
173.1
100.3
192.3
67.0
5400
80
163.6
159.3
179.5
129.6
199.4
96.2
158.5
155.3
172.9
127.0
192.1
93.6
85
171.2
168.0
179.5
151.7
199.2
118.2
166.2
163.1
173.1
149.0
191.9 115.8
90
179.2
175.9
181.2
171.8
199.1
140.3
174.2
170.9
175.2
168.4
191.9 137.7
75
162.9
140.7
181.5
105.7
201.5
70.2
157.1
138.0
174.8
103.1
194.1
67.7
5850
80
166.6
163.5
181.3
134.2
201.3
98.6
161.7
158.6
174.7
131.5
194.0
96.0
85
174.9
171.6
181.5
157.5
201.2
122.1
169.7
166.5
175.0
154.6
193.8 119.5
90
183.2
179.7
184.0
177.7
201.1
145.5
177.9
174.5
178.1
173.8
193.7 142.9
75
164.6
145.3
183.2
108.4
203.2
70.9
158.7
142.5
176.4
105.8
195.7
68.3
6300
80
169.8
166.6
183.0
138.4
203.1
100.9
164.6
161.5
176.2
135.8
195.6
98.4
85
178.2
174.8
183.4
163.0
202.9
125.8
172.9
169.6
176.9
160.1
195.4 123.2
90
186.8
183.2
186.9
182.6
202.8
150.6
181.2
177.7
181.2
177.7
195.3 148.0
75
166.2
149.7
184.5
111.0
204.8
71.6
160.3
146.7
177.8
108.4
197.1
69.0
6750
80
172.6
169.3
184.4
142.7
204.6
103.2
167.3
164.1
177.6
140.1
196.9 100.6
85
181.3
177.8
185.2
168.1
204.5
129.4
175.7
172.4
178.6
165.0
196.7 126.9
90
190.0
186.4
189.8
186.3
204.3
155.6
184.2
180.8
184.1
180.6
196.6 153.0
Table PD-15 — Gross Cooling Capacities SRVE-150 (Cont.)
English
Ambient Temperature (°F)
105
115
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(ºF)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
75
149.2
130.4
166.3
97.7
184.8
64.4
143.1
127.4
159.3
94.8
177.0
61.8
5400
80
153.4
150.5
166.2
124.3
184.5
91.0
148.0
145.2
159.2
121.6
176.8
88.4
85
161.0
158.0
166.4
146.1
184.4
113.0
155.5
152.6
159.6
143.1
176.7 110.4
90
168.8
165.6
169.1
164.5
184.3
135.1
163.0
160.0
162.9
159.8
176.6 132.4
75
150.9
135.1
167.9
100.4
186.5
65.1
144.7
132.0
161.3
97.7
178.5
62.4
5850
80
156.5
153.5
167.8
128.8
186.2
93.4
150.9
148.1
160.7
126.0
178.4
90.8
85
164.3
161.2
168.3
151.6
186.1
116.9
158.6
155.6
161.5
148.5
178.2 114.2
90
172.3
169.0
172.1
168.9
186.0
140.3
166.3
163.2
166.2
163.1
178.1 137.6
75
152.5
139.5
169.4
103.1
187.9
65.7
146.3
136.1
162.1
100.3
179.9
63.1
6300
80
159.2
156.2
169.2
133.1
187.7
95.8
153.6
150.7
162.0
130.3
179.7
93.1
85
167.3
164.1
170.1
156.8
187.6
120.6
161.4
158.4
163.2
153.4
179.6 117.9
90
175.4
172.1
175.3
172.0
187.5
145.4
169.4
166.2
169.3
166.1
179.5 142.7
75
154.0
143.5
170.7
105.7
189.2
66.4
147.7
140.0
163.2
102.9
181.0
63.8
6750
80
161.8
158.7
170.4
137.3
189.0
98.0
155.9
153.0
163.1
134.5
180.8
95.3
85
170.0
166.8
171.8
161.6
188.9
124.2
164.0
160.9
164.9
157.9
180.7 121.5
90
178.3
174.9
178.2
174.8
188.8
150.3
172.0
168.8
172.0
168.8
180.7 147.5
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Performance
Data
Air Cooled
60 Hz
