Electrical
Data
Table ED-1 — Genius – Electrical Features - SRVE/SIVE 050
Nominal Operation Values Compressor Fan Motor Fan Motor Consumption Current
Fan Voltage KW CNO KW CNO KW CNO KW A
STD 220V 15.40 3.04 3.04 21.48
and 380V 4.74 8.92 0.83 1.76 0.83 1.76 6.40 12.44
Option 1 440V 7.70 1.52 1.52 10.74
220V 15.40 4.14 3.04 22.58
Option 2 380V 4.74 8.92 1.22 2.39 0.83 1.76 6.79 13.07
440V 7.70 2.07 1.52 11.29
Plenum Box 220V 15.40 1.80 3.04 20.24
Option 380V 4.74 8.92 0.45 1.04 0.83 1.76 6.02 11.72
440V 7.70 0.90 1.52 10.12
Maximum Operation Values Compressor Fan Motor Fan Motor Current
Fan Voltage CMO CMO CMO A
STD 220V 19.90 3.80 3.80 27.50
and 380V 11.52 2.19 2.19 15.90
Option 1 440V 9.95 1.90 1.90 13.75
220V 19.90 5.18 3.80 28.88
Option 2 380V 11.52 2.99 2.19 16.70
440V 9.95 1.13 1.90 12.98
Plenum Box 220V 19.90 2.25 3.80 25.95
Option 380V 11.52 1.30 2.19 15.01
440V 9.95 1.13 1.90 12.98
Start-up Values Compressor Fan Motor Fan Motor
Fan Voltage LRA LRA LRA
STD 220V 128.00 19.00 19.00
and 380V 74.10 11.00 11.00
Option 1 440V 64.00 9.50 9.50
220V 128.00 28.60 19.00
Option 2 380V 74.10 16.56 11.00
440V 64.00 14.30 9.50
Plenum Box 220V 128.00 9.90 19.00
Option 380V 74.10 5.73 11.00
440V 64.00 4.95 9.50
• To know which ventilation option should be used, consult the behavior of the
ventilation options.
• CNO = Nominal operation current (A).
• CMO = Maximum operation current.
• LRA = Locked rotor amps.
• STD Option and Option 1 - evaporator fan motor -1 CV.
•
Option 2 - evaporator fan motor -1.5 CV.
• Plenum box option - evaporator fan motor -0.5 CV.
•
Power of the condenser fan motor -1 CV.
• Size the electrical wiring using the maximum operation currents.
Each unit model has three options for
electric heat.
The following table shows the options
and their capacities in kW.
Model 5 Ton 7.5 Ton 10 Ton 12.5 Ton 15 Ton
Option 1 2 kW 3 kW 4 kW 5 kW 6 kW
Option 2 4 kW 6 kW 8 kW 2x5 kW 2x6 kW
Option 3 6 kW 9 kW 2x6 kW 2x8 kW 2x9 kW
