Table PD-9 — Gross Cooling Capacities SAVE-125
English
ENT Water Temp (°F)
75
85
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
135.8
109.8
31.3
151.7
85.3
34.4
169.3
60.3
37.9
131.7
107.9
31.3
147.4
83.5
34.4
164.4
58.5
37.4
4500
80
136.1
129.4
31.7
151.6
105.3
34.4
169.1
80.3
37.9
132.3
127.2
31.3
147.3
103.4
34.4
164.3
78.4
37.4
85
140.1
140.1
32.2
151.5
121.8
34.4
168.9
96.8
37.9
136.8
136.8
32.2
147.1
119.9
34.4
164.1
95.0
37.4
90
146.6
146.6
33.5
151.6
138.1
34.4
168.7
113.2
37.9
143.2
143.2
33.5
147.5
136.1
34.4
164.0
111.5
37.4
75
137.3
113.5
31.7
153.6
87.4
34.8
171.3
60.9
38.3
133.2
111.5
31.7
149.1
85.5
34.8
166.3
59.1
37.9
4875
80
138.2
133.7
31.7
153.5
108.6
34.8
171.0
82.0
38.3
134.3
131.4
31.7
149.3
107.0
34.8
166.1
80.2
37.9
85
143.2
143.2
32.6
153.3
126.2
34.8
170.8
99.6
38.3
139.9
139.9
32.6
148.9
124.3
34.8
165.9
97.8
37.9
90
149.9
149.9
33.9
153.7
143.2
34.8
170.7
117.0
38.3
146.5
146.5
33.9
149.4
141.0
34.8
165.9
115.3
37.9
75
138.9
117.0
32.2
155.3
89.4
35.2
172.8
61.5
38.8
134.7
115.0
31.7
150.7
87.5
34.8
167.9
59.6
38.3
5250
80
140.3
137.7
32.2
155.1
111.7
35.2
172.7
83.8
38.8
136.4
134.9
32.2
150.5
109.8
34.8
167.7
82.0
38.3
85
146.2
146.2
33.5
154.9
130.3
35.2
172.6
102.4
38.8
142.7
142.7
33.5
150.4
128.4
34.8
167.7
100.5
38.3
90
153.1
153.1
34.8
155.7
147.9
35.2
172.4
120.8
38.3
149.5
149.5
34.8
151.4
145.6
35.2
167.5
119.0
38.3
75
140.2
120.2
32.2
156.7
91.2
35.2
174.4
62.0
38.8
136.0
119.4
32.2
151.9
89.4
35.2
169.4
60.2
38.8
5625
80
140.7
140.0
32.6
156.5
114.9
35.2
174.2
85.5
38.8
138.5
138.0
32.6
151.9
113.0
35.2
169.2
83.7
38.8
85
148.8
148.8
33.9
156.3
134.3
35.2
174.1
104.9
38.8
145.2
145.2
33.9
151.7
132.4
35.2
169.1
103.1
38.8
90
155.9
155.9
35.2
157.6
152.1
35.7
174.0
124.3
38.8
152.1
152.1
35.2
153.4
149.7
35.7
168.9
122.4
38.8
Table PD-9 — Gross Cooling Capacities SAVE-125 (Cont.)
ENT Water Temp (°F)
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
127.6
105.9
31.3
142.9
81.6
33.9
159.5
56.7
37.4
4500
80
128.4
124.8
31.3
142.7
101.4
33.9
159.4
76.7
37.4
85
133.4
133.4
32.2
142.6
118.0
33.9
159.2
93.1
37.4
90
139.7
139.7
33.5
143.0
134.0
34.4
159.1
109.5
37.4
75
129.0
109.6
31.3
144.5
83.5
34.4
161.2
57.3
37.9
4875
80
132.6
128.7
31.7
144.4
104.7
34.4
161.0
78.4
37.9
85
136.4
136.4
33.0
144.2
122.3
34.4
161.0
96.0
37.9
90
142.9
142.9
34.4
145.0
138.7
34.8
160.8
113.4
37.9
75
130.3
113.0
31.7
146.0
85.6
34.8
162.8
57.9
37.9
5250
80
132.6
132.0
32.2
145.8
107.9
34.8
162.5
80.1
37.9
85
139.0
139.0
33.5
145.6
126.4
34.8
162.4
98.7
37.9
90
145.8
145.8
34.8
147.0
143.1
34.8
162.2
117.0
37.9
75
131.6
116.2
32.2
147.2
87.5
34.8
164.1
58.3
38.3
5625
80
134.7
134.6
32.6
147.1
111.0
34.8
163.9
81.8
38.3
85
141.5
141.5
33.9
147.0
130.4
34.8
163.8
101.3
38.3
90
148.4
148.4
35.2
161.5
147.0
35.2
163.7
120.6
38.3
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Capacity Correction Factor Table
Delta T
Water
Total Cap.
Sens. Cap.
(°F)
GPM
MBh
MBh
4.5
2.21
1.01
1.01
7.2
1.39
1.01
1.01
10.0
1.00
1.00
1.00
12.6
0.79
0.99
1.00
15.3
0.66
0.99
1.00
18.0
0.56
0.98
0.99
Performance
Data
Water Cooled
60 Hz
