Performance data water cooled 60 hz – Trane Genius PKG-PRC007-EN User Manual
Page 24
PKG-PRC007-EN
24
Table PD-10 — Gross Cooling Capacities SAVE-150
English
ENT Water Temp (°F)
75
85
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
165.6
138.7
37.9
185.4
106.0
41.4
206.9
72.8
45.8
160.4
136.3
37.4
179.6
103.6
41.4
200.2
70.4
45.4
5400
80
167.7
163.2
38.3
185.2
132.7
41.4
206.6
99.4
45.8
163.0
160.0
37.9
179.3
130.3
41.4
200.0
97.1
45.4
85
175.0
173.4
39.6
185.1
154.9
41.4
206.4
121.6
45.8
170.6
169.0
39.6
179.3
152.4
41.4
199.9
119.2
45.4
90
183.4
181.7
41.0
186.5
175.6
41.9
206.3
143.5
45.8
178.8
177.1
41.0
181.0
172.6
41.4
199.7
141.2
45.4
75
167.6
143.7
38.3
187.5
108.8
41.9
209.1
73.5
46.3
162.3
141.2
37.9
181.3
106.4
41.4
202.3
71.1
45.8
5850
80
170.7
168.2
38.8
187.3
137.3
41.9
208.8
101.9
46.3
166.0
164.3
38.8
181.2
135.1
41.4
202.1
99.5
45.8
85
179.0
177.3
40.5
187.3
160.8
41.9
208.6
125.4
46.3
174.4
172.7
40.1
181.4
158.2
41.4
202.0
123.0
45.8
90
187.6
185.8
41.9
189.4
182.0
42.3
208.5
148.8
46.3
182.9
181.2
41.9
183.9
178.8
42.3
201.8
146.4
45.8
75
169.5
148.4
38.3
189.3
111.5
42.3
210.9
74.3
46.7
164.1
145.8
38.3
183.2
109.1
41.9
204.1
71.9
46.3
6300
80
173.8
172.1
39.2
189.2
141.6
42.3
210.8
104.3
46.7
169.2
167.5
39.2
183.0
139.2
41.9
203.9
101.9
45.8
85
182.6
180.9
41.0
189.4
166.4
42.3
210.6
129.2
46.7
177.8
176.1
41.0
183.4
163.7
41.9
203.8
126.8
45.8
90
191.4
189.6
42.7
192.3
187.6
42.7
210.5
154.0
46.7
186.5
184.7
42.7
186.8
184.0
42.7
203.7
151.6
45.8
75
171.2
152.9
38.8
191.0
114.2
42.7
212.7
74.9
46.7
164.1
150.2
38.8
184.8
111.7
42.3
205.8
72.6
46.3
6750
80
176.8
175.1
40.1
190.8
145.9
42.7
212.5
106.6
46.7
172.1
170.5
39.6
184.6
143.4
42.3
205.6
104.2
46.3
85
185.9
184.1
41.9
191.3
171.7
42.7
212.4
132.8
46.7
180.9
179.2
41.4
185.3
169.0
42.3
205.4
130.4
46.3
90
194.9
193.0
43.6
195.1
192.5
43.6
212.2
158.9
46.7
189.8
188.0
43.2
189.7
187.9
43.2
205.3
156.5
46.3
Table PD-10 — Gross Cooling Capacities SAVE-150 (Cont.)
ENT Water Temp (°F)
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
155.0
133.7
37.4
173.4
101.1
41.0
193.4
68.0
44.9
5400
80
158.0
156.2
37.9
173.3
127.8
41.0
193.2
94.6
44.9
85
165.9
164.3
39.6
173.4
149.8
41.0
193.1
116.8
44.9
90
174.0
172.3
41.0
175.4
169.5
41.4
192.9
138.7
44.9
75
156.8
138.5
37.9
175.2
103.9
41.4
195.3
68.7
45.4
5850
80
161.3
159.7
38.8
175.0
132.3
41.4
195.2
97.1
45.4
85
169.6
168.0
40.1
175.4
155.6
41.4
195.0
120.6
45.4
90
177.9
176.2
41.9
178.3
175.0
41.9
194.9
144.0
45.4
75
158.4
143.1
37.9
176.8
106.6
41.4
197.0
69.5
45.8
6300
80
164.3
162.8
39.2
176.7
136.7
41.4
196.9
99.4
45.8
85
172.8
171.2
41.0
177.2
161.0
41.9
196.7
124.4
45.4
90
181.3
179.6
42.3
181.3
179.5
42.3
196.6
149.1
45.4
75
160.0
147.4
38.3
178.3
109.2
41.9
198.6
70.1
45.8
6750
80
167.2
165.6
39.6
178.1
140.9
41.9
198.3
101.7
45.8
85
175.8
174.1
41.4
179.0
166.1
42.3
198.2
127.9
45.8
90
184.5
182.7
43.2
184.5
182.7
43.2
198.0
154.0
45.8
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Performance
Data
Water Cooled
60 Hz
Capacity Correction Factor Table
Delta T
Water
Total Cap.
Sens. Cap.
(°F)
GPM
MBh
MBh
4.5
2.21
1.01
1.01
7.2
1.39
1.01
1.01
10.0
1.00
1.00
1.00
12.6
0.79
0.99
1.00
15.3
0.66
0.99
1.00
18.0
0.56
0.98
0.99
