11 PKG-PRC007-EN
Three transmission options exist for the
evaporator fan motor: Std. option,
option 1, option 2. In addition, there is an
option for those cases in which the unit
is operated with a plenum box. The
motors for each transmission option can
be found in the general facts tables.
Performance
Data Fan
Data
Table PD-1 — Fan Performance SRVE/SIVE/SAVE 5 Tons
External static pressure with permanent air filter inches of water (Pa)
.08 .16 .24 .31 .39 .50
Model Airflow (19.9) (39.8) (59.8) (77.2) (97.1) (124.5)
Option 5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1802 3060 815 0.40 852 0.43 888 0.45 923 0.48 957 0.51 990 0.54
MT 1.0 CV 1877 3188 843 0.45 879 0.48 914 0.51 948 0.53 981 0.57
MS: 78,5 A 106,5 1952 3315 869 0.50 904 0.53 938 0.56 971 0.59 1003 0.62
STD FS: 184 (8") 2028 3443 897 0.56 931 0.59 964 0.62 996 0.65
B: 1X A36 2102 3570 925 0.62 957 0.65 989 0.68
2178 3698 952 0.68 984 0.71
2253 3825 981 0.75
External static pressure with permanent air filter inches of water (Pa)
.94 1.10 1.26 1.42 1.57
Model Airflow (234.1) (273.9) (313.7) (353.6) (390.9)
Option 5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1802 3060 1289 0.91 1343 0.98 1395 1.05
MT 1.5 CV 1877 3188 1305 0.97 1358 1.05 1409 1.12
MS: 78.5 A 106.5 1952 3315 1267 0.95 1320 1.03 1372 1.11 1422 1.19
OP2 BS: 108 (5") 2028 3443 1284 1.02 1337 1.10 1387 1.18 1437 1.25
B: 1X A31 2102 3570 1302 1.09 1353 1.16 1403 1.24 1452 1.32
2178 3698 1269 1.08 1320 1.15 1371 1.23 1420 1.31 1467 1.39
2253 3825 1289 1.14 1340 1.22 1389 1.30 1437 1.39
MT = Motor (CV).
MS = Motor Sheave, variable pitch (mm).
FS = Fan Sheave (mm).
B
= Belt.
External static pressure with permanent air filter inches of water (Pa)
.16 .24 .31 .39 .50 .63 .79 .94 1.10
Model Airflow (39.8) (59.8) (77.2) (97.1) (124.5) (156.9) (196.7) (234.1) (273.9)
Option 5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1802 3060 1055 0.61 1117 0.68 1176 0.75 1234 0.83
MT 1.0 CV 1877 3188 1013 0.60 1076 0.67 1136 0.74 1195 0.81 1251 0.89
MS: 78,5 A 106,5 1952 3315 1035 0.66 1096 0.73 1155 0.80 1212 0.88
OP1 FS: 133 (6") 2028 3443 1027 0.68 1058 0.72 1117 0.79 1175 0.86 1230 0.94
B: 1X A32 2102 3570 1020 0.71 1051 0.75 1081 0.78 1139 0.85 1195 0.93 1249 1.01
2178 3698 1015 0.74 1045 0.78 1075 0.81 1104 0.85 1160 0.92 1215 1.00
2253 3825 1012 0.78 1042 0.81 1071 0.85 1100 0.88 1128 0.92 1183 0.99 1237 1.07
