Table PD-13 — Gross Cooling Capacities SRVE-100
Metric
Ambient Temperature (°C)
29.5
35.0
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(ºC)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
31.4
25.4
35.2
19.4
39.3
13.3
30.4
24.9
34.1
18.9
38.0
12.8
6120
27
31.6
30.1
35.1
24.3
39.2
18.2
30.6
29.6
34.0
23.8
38.0
17.7
29
32.5
32.5
35.1
28.3
39.2
22.2
31.7
31.7
34.0
27.8
37.9
21.7
32
34.1
34.1
35.2
32.3
39.2
26.2
33.2
33.2
34.1
31.7
37.9
25.7
24
31.8
26.3
35.6
19.9
39.7
13.4
30.8
25.8
34.5
19.4
38.4
13.0
6630
27
32.0
31.2
35.6
25.1
39.7
18.6
31.1
30.6
34.4
25.1
38.4
18.1
29
33.3
33.3
35.5
29.4
39.6
22.9
32.4
32.4
34.4
28.9
38.4
22.4
32
34.9
34.9
35.6
33.4
39.6
27.1
34.0
34.0
34.6
32.9
38.3
26.6
24
32.2
27.1
36.0
20.4
40.1
13.6
31.1
26.6
34.8
19.9
38.8
13.1
7140
27
32.5
32.1
35.9
25.8
40.0
19.0
31.6
31.4
34.8
25.4
38.7
18.6
29
34.0
34.0
35.9
30.3
40.0
23.5
33.1
33.1
34.7
29.9
38.7
23.2
32
35.6
35.6
36.1
34.6
40.0
28.0
34.7
34.7
35.0
34.0
38.7
27.5
24
32.4
27.9
36.3
20.9
40.4
13.7
31.4
27.4
35.1
20.4
39.1
13.2
7650
27
33.0
32.9
36.2
26.6
40.4
19.4
32.1
32.1
35.1
26.1
39.1
18.9
29
34.6
34.6
36.2
31.3
40.3
24.1
33.7
33.7
35.1
30.8
39.0
23.7
32
36.3
36.3
36.6
35.6
40.3
28.8
35.4
35.4
35.5
35.0
39.0
28.4
Table PD-13 — Gross Cooling Capacities SRVE-100 (Cont.)
Metric
Ambient Temperature (°C)
40.5
46
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(ºC)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
29.4
24.5
32.9
18.5
36.7
12.4
28.4
24.0
31.7
17.9
35.2
11.8
6120
27
29.6
29.0
32.9
23.3
36.7
17.2
28.7
28.4
31.7
22.8
35.2
16.7
29
30.9
30.9
32.9
27.3
36.6
21.2
30.0
30.0
31.6
26.8
35.2
20.7
32
32.4
32.4
33.0
31.2
36.6
25.2
31.4
31.4
31.8
30.6
35.1
24.7
24
29.8
25.3
33.3
18.9
37.0
12.5
28.7
24.8
32.0
18.4
35.6
12.0
6630
27
30.1
29.9
33.2
24.1
37.0
17.6
29.2
29.2
32.0
23.6
35.5
17.1
29
31.6
31.6
33.2
28.4
37.0
21.9
30.6
30.6
32.0
27.8
35.5
21.4
32
33.1
33.1
33.5
32.3
24.3
26.2
32.1
32.1
32.3
31.6
35.5
25.6
24
30.1
26.2
33.6
19.4
37.4
12.6
29.0
25.6
32.3
18.9
35.9
12.1
7140
27
30.7
30.6
33.6
24.9
37.4
18.0
29.7
29.7
32.3
24.3
35.8
17.5
29
32.2
32.2
33.6
29.4
37.3
22.5
31.2
31.2
32.3
28.8
35.8
22.0
32
33.8
33.8
33.9
33.3
37.3
27.0
32.7
32.7
32.8
32.5
35.8
26.5
24
30.3
27.0
33.9
19.9
37.7
12.7
29.3
26.4
32.6
19.4
36.1
12.2
7650
27
31.2
31.2
33.9
25.6
37.7
18.4
30.2
30.2
32.5
25.1
36.1
17.9
29
32.8
32.8
33.9
30.3
37.6
23.2
31.7
31.7
32.6
29.8
36.1
22.6
32
34.4
34.4
34.4
34.2
37.6
27.9
33.3
33.3
33.2
33.2
36.0
27.3
Notes:
TGC = Total Gross Capacity (kW)
SHC = Sensible Heat Capacity (kW)
