PKG-PRC007-EN 38
Electrical
Data
Table ED-2 — Genius – Electrical Features - SRVE/SIVE 050
Nominal Operation Values Compressor Fan Motor Fan Motor Consumption Current
Fan Voltage KW CNO KW CNO KW CNO KW A
220V 18.60 4.14 7.32 30.06
STD 380V 6.39 10.77 1.22 2.39 2.23 4.23 9.84 17.39
440V 9.30 2.07 3.65 15.02
220V 18.60 5.53 7.32 31.45
Option 1 380V 6.39 10.77 1.64 3.19 2.23 4.23 10.26 18.19
440V 9.30 2.76 3.65 15.71
220V 18.60 7.32 7.32 33.24
Option 2 380V 6.39 10.77 2.23 4.23 2.23 4.23 10.85 19.23
440V 9.30 3.66 3.65 16.61
Plenum Box 220V 18.60 7.32 7.32 33.24
Option 380V 6.39 10.77 0.45 1.04 2.23 4.23 9.07 16.04
440V 9.30 0.90 3.65 13.85
Maximum Operation Values Compressor Fan Motor Fan Motor Current
Fan Voltage CMO CMO CMO A
220V 24.98 5.18 9.15 39.32
STD 380V 14.46 2.99 5.28 22.73
440V 12.49 2.59 4.58 19.66
220V 24.98 6.91 9.15 41.04
Option 1 380V 14.46 3.99 5.28 23.73
440V 12.49 3.46 4.58 20.52
220V 24.98 9.15 9.15 43.28
Option 2 380V 14.46 5.28 5.28 25.02
440V 12.49 4.58 4.58 21.64
Plenum Box 220V 24.98 2.25 9.15 36.38
Option 380V 14.46 1.30 5.28 21.04
440V 12.49 1.13 4.58 18.19
Start-up Values Compressor Fan Motor Fan Motor
Fan Voltage LRA LRA LRA
220V 171.00 30.92 60.45
STD 380V 99.00 17.85 34.90
440V 85.50 15.46 30.23
220V 171.00 48.36 60.45
Option 1 380V 99.00 27.92 34.90
440V 85.50 24.18 30.23
220V 171.00 60.45 60.45
Option 2 380V 99.00 34.90 34.90
440V 85.50 30.23 30.23
Plenum Box 220V 171.00 11.25 60.45
Option 380V 99.00 6.50 34.90
440V 85.50 5.63 30.23
• To know which ventilation option should be used, consult the behavior of the
ventilation options.
•
CNO = Nominal operation current (A).
• CMO = Maximum operation current.
•
LRA = Locked rotor amps.
• STD Option - evaporator fan motor -1.5 CV.
• Option 1 - evaporator fan motor -2 CV.
•
Option 2 - evaporator fan motor -3 CV.
• Plenum box option - evaporator fan motor -0.5 CV.
•
Power of the condenser fan motor -3 CV.
• Size the electrical wiring using the maximum operation currents.
